Appendix
A-557SJ62 Manual
C53000-G1140-C121-1
Interlocking: 52 Open (52 Open) IntSP O/O
Interlocking: 52 Close (52 Close) IntSP O/O
Interlocking: Disconnect switch Open
(Disc.Open)
IntSP O/O
Interlocking: Disconnect switch Close
(Disc.Close)
IntSP O/O
Interlocking: Ground switch Open
(GndSw Open)
IntSP O/O
Interlocking: Ground switch Close
(GndSw Cl.)
IntSP O/O
Block Data Transmission to SCADA
(Block Data)
IntSP O/O
Q2 Open/Close (Q2 Op/Cl) CF_D2 O/O REL OM O/O GI 240 162 1 GI
Q2 Open/Close (Q2 Op/Cl) DP O/O BI OM CB O/O GI 240 162 1 GI
Q9 Open/Close (Q9 Op/Cl) CF_D2 O/O REL OM O/O GI 240 163 1 GI
Q9 Open/Close (Q9 Op/Cl) DP O/O BI OM CB O/O GI 240 163 1 GI
Fan ON/OFF (Fan ON/OFF) CF_D2 O/O REL OM O/O GI 240 175 1 GI
Fan ON/OFF (Fan ON/OFF) DP O/O BI OM CB O/O GI 240 175 1 GI
>CB ready Spring is charged (>CB
ready)
SP LED BI REL OM CB O/O GI
>Door closed (>DoorClose) SP LED BI REL OM CB O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
