Appendix
A-56 7SJ62 Manual
C53000-G1140-C121-1
>Cabinet door open (>Door open) SP O/O LED BI REL OM CB O/O GI 101 1 1 GI
>CB waiting for Spring charged (>CB
wait)
SP O/O LED BI REL OM CB O/O GI 101 2 1 GI
>No Voltage (Fuse blown) (>No Volt.) SP O/O LED BI REL CB O/O GI 160 38 1 GI
>Error Motor Voltage (>Err Mot V) SP O/O LED BI REL OM CB O/O GI 240 181 1 GI
>Error Control Voltage (>ErrCntrlV) SP O/O LED BI REL OM CB O/O GI 240 182 1 GI
>SF6-Loss (>SF6-Loss) SP O/O LED BI REL OM CB O/O GI 240 183 1 GI
>Error Meter (>Err Meter) SP O/O LED BI REL OM CB O/O GI 240 184 1 GI
>Transformer Temperature (>Tx Temp.) SP O/O LED BI REL OM CB O/O GI 240 185 1 GI
>Transformer Danger (>Tx Danger) SP O/O LED BI REL OM CB O/O GI 240 186 1 GI
601 Ia (Ia =) MV O/O GI 134 137 9
602 Ib (Ib =) MV O/O GI 160
134
145
137
3
9
603 Ic (Ic =) MV O/O GI 134 137 9
604 In (In =) MV O/O GI 134 137 9
605 I1 (positive sequence) (I1 =) MV O/O GI
606 I2 (negative sequence) (I2 =) MV O/O GI
831 3Io (zero sequence) (3Io =) MV O/O GI
621 Va (Va =) MV O/O GI 134137 9
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
