Appendix
A-577SJ62 Manual
C53000-G1140-C121-1
622 Vb (Vb =) MV O/O GI 134137 9
623 Vc (Vc =) MV O/O GI 134 137 9
624 Va-b (Va-b=) MV O/O GI 160
134
145
137
3
9
625 Vb-O (Vb-c=) MV O/O GI 134137 9
626 Vc-a (Vc-a=) MV O/O GI 134 137 9
627 VN (VN =) MV O/O GI
629 V1 (positive sequence) (V1 =) MV O/O GI
630 V2 (negative sequence) (V2 =) MV O/O GI
641 P (active power) (P =) MV O/O GI 134 137 9
642 Q (reactive power) (Q =) MV O/O GI 134 137 9
645 S (apparent power) (S =) MV O/O GI
644 Frequency (Freq=) MV O/O GI 134 137 9
832 3Vo (zero sequence) (3Vo =) MV O/O GI
901 Power Factor (PF =) MV O/O GI 134 137 9
830 INs Senstive Ground Fault Current (INs
=)
MV O/O GI
701 Resistive ground current in isol systems
(INs Real)
MV O/O GI 134137
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
