Appendix
A-58 7SJ62 Manual
C53000-G1140-C121-1
702 Reactive ground current in isol systems
(INs Reac)
MV O/O GI 134137
806 Temperature of Stator (Θ Stator) MV O/O GI
805 Temperature of Rotor (Θ Rotor) MV O/O GI
963 I A demand (Ia dmd=) MV O/O GI
964 I B demand (Ib dmd=) MV O/O GI
965 I C demand (Ic dmd=) MV O/O GI
833 I1 (positive sequence) Demand (I1
dmd=)
MV O/O GI
834 Active Power Demand (P dmd =) MV O/O GI
835 Reactive Power Demand (Q dmd =) MV O/O GI
836 Apparent Power Demand (S dmd =) MV O/O GI
Reset Minimum and Maximum counter
(ResMinMax)
IntSP_Ev O O/O GI
395 >I MIN/MAX Buffer Reset (>I MinMax
Reset)
SP O BI REL O/O GI
396 >I1 MIN/MAX Buffer Reset (>I1 MiMa-
Reset)
SP O BI REL O/O GI
403 >Idmd MIN/MAX Buffer Reset (>Idmd
MiMaReset)
SP O BI REL O/O GI
851 Ia Min (Ia Min=) MVT O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
