Appendix
A-597SJ62 Manual
C53000-G1140-C121-1
852 Ia Max (Ia Max=) MVT O/O GI
853 Ib Min (Ib Min=) MVT O/O GI
854 Ib Max (Ib Max=) MVT O/O GI
855 Ic Min (Ic Min=) MVT O/O GI
856 Ic Max (Ic Max=) MVT O/O GI
857 I1 (positive sequence) Minimum (I1
Min=)
MVT O/O GI
858 I1 (positive sequence) Maximum (I1
Max=)
MVT O/O GI
837 I A Demand Minimum (IAdmdMin) MVT O/O GI
838 I A Demand Maximum (IAdmdMax) MVT O/O GI
839 I B Demand Minimum (IBdmdMin) MVT O/O GI
840 I B Demand Maximum (IBdmdMax) MVT O/O GI
841 I C Demand Minimum (ICdmdMin) MVT O/O GI
842 I C Demand Maximum (ICdmdMax) MVT O/O GI
843 I1 (positive sequence) Demand Mini-
mum (I1dmdMin)
MVT O/O GI
844 I1 (positive sequence) Demand Maxi-
mum (I1dmdMax)
MVT O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
