The SINAUT Configuration Tool
6.4 The connection configuration
TIM DNP3
146 System Manual, 06/2014, C79000-G8976-C253-03
Figure 6-3 The Connection configuration window of the SINAUT configuration tool
In the right-half of the window, the possible connections are listed in a tree structure resulting
from the network configuration in NetPro. The connections actually required and used for
communication in the telecontrol system installation must be transferred from the right-hand
to the left-hand window configured connections.
The two lists display the number of connections involved.
The entries in the connection tables must be interpreted as follows:
Table 6- 1 Symbols in the connection list of the connection configuration
1
Connection starting point
2
Connection end point
3
Alternative path
4
Connection node over which the connection runs
Invalid connections are displayed in red as shown in the example of a connection that no
longer exists due to reconfiguration (see figure).
The labeling of the individual connection point in the basic setting describes the relevant
subscriber with:
Subscriber number / Station name / Module / Interface.
Example: 5 / Station 3 / CPU 312 / MPI (2)
