The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
182 System Manual, 06/2014, C79000-G8976-C253-03
Data object
Object type and function
Number of
indexes
occupied
DNP3 object group
[variation]
(S7 data type)
DNP3 level *
Use in stations
type **
Analog value / mean value objects
Ana04W_S
Analog value object for send
direction
Send 4 analog values (16-bit
value)
4
• 30 [2] (WORD)
• 32 [2] (WORD)
• 32 [4] (WORD)
• 41 [2] (WORD)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• S
• S
• S
• M
Ana04W_R
Analog value object for receive
direction
Receive 4 analog values (16-bit
value)
4
• 30 [2] (WORD)
• 32 [2] (WORD)
• 32 [4] (WORD)
• 41 [2] (WORD)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• M
• M
• M
• S
Mean04W_S
Mean value object for send
direction
Send 4 mean values (16-bit
value)
4
• 30 [2] (WORD)
• 32 [2] (WORD)
• 32 [4] (WORD)
• 41 [2] (WORD)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• S
• S
• S
• M
Mean04W_R
Mean value object for receive
direction
Receive 4 mean values (16-bit
value)
4
• 30 [2] (WORD)
• 32 [2] (WORD)
• 32 [4] (WORD)
• 41 [2] (WORD)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• M
• M
• M
• S
Counted value objects
Cnt01D_S
Counted value object for send
direction
Send 1 counted value
1
• 20 [2] (WORD)
• 21 [2] (WORD)
• 21 [6] (WORD)
• 22 [2] (WORD)
• 22 [6] (WORD)
• 23 [2] (WORD)
• 1 ... 5
• 1 ... 4
• 5
• 1 ... 4
• 5
• 1 ... 5
S
Cnt01D_R
Counted value object for
receive direction
Receive 1 counted value
1
• 20 [2] (WORD)
• 22 [2] (WORD)
• 22 [6] (WORD)
• 1 ... 5
• 1 ... 4
• 5
M
Cnt04D_S
Counted value object for send
direction
Send 4 x 1 counted value
4
• 20 [2] (WORD)
• 21 [2] (WORD)
• 21 [6] (WORD)
• 22 [2] (WORD)
• 22 [6] (WORD)
• 1 ... 5
• 1 ... 4
• 5
• 1 ... 4
• 5
S
Cnt04D_R
Counted value object for
receive direction
Receive 4 x 1 counted value
4
• 20 [2] (WORD)
• 22 [2] (WORD)
• 22 [6] (WORD)
• 1 ... 5
• 1 ... 4
• 5
M
