The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
181
System object
Function
PartnerStatus Displays the status of the connection with a maximum of 8 communications
partners
Signals to the CPU whether communication with a partner "DNP3 master
station" is functioning or disrupted.
OpInputMonitor Signals detection of hardware entries
Indicates the status of operator input to the CPU (with command, setpoint,
and parameter input).
Is not normally used with the DNP3 protocol.
System objects for MODBUS communication
ModbusGateway Configuration of the MODBUS protocol for a serial interface of the TIM
The use of the MODBUS protocol for a serial interface of the DNP3 TIM is
specified using the "ModbusGateway" object. The interface and various
connection parameters are configured with this object.
ModbusPartnerStatus Displays connection status of max. 8 MODBUS slaves
Signals to the CPU whether communication with a partner "MODBUS slave"
is functioning or disrupted.
System objects not supported
SmServiceCenter
The object is not supported for the DNP3 protocol.
Table 6- 6 Data objects of TD7onTIM
Data object
Object type and function
Number of
indexes
occupied
DNP3 object group
[variation]
(S7 data type)
DNP3 level *
Use in stations
type **
Message / binary objects
Bin04B_S
Binary value object for send
direction
Send 4 bytes of binary
information
32 (4 x 8)
• 1 [2] (BOOL)
• 2 [2] (BOOL)
• 12 [1] (BOOL)
1 ... 5
• S
• S
• M
Bin04B_R
Binary value object for receive
direction
Receive 4 bytes of binary
information
32 (4 x 8)
• 1 [2] (BOOL)
• 2 [2] (BOOL)
• 12 [1] (BOOL)
1 ... 5
• M
• M
• S
Bin08X_S
Binary value object for send
direction
Send 8 x 1 bits of binary
information independently of
each other
8
• 10 [2] (BOOL)
***
• 11 [2] (BOOL)
***
• 12 [1] (BOOL)
****
• 1 ... 5
• 4 ... 5
• 1 ... 5
• S
• S
• M
Bin08X_R
Binary value object for receive
direction
Receive 8 x 1 bit of binary
information
8
• 10 [2] (BOOL)
***
• 11 [2] (BOOL)
***
• 12 [1] (BOOL)
• 1 ... 5
• 4 ... 5
• 1 ... 5
• M
• M
• S
