The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
180 System Manual, 06/2014, C79000-G8976-C253-03
Copying parameters to other destination subscribers
Once the destination subscriber-specific parameters have been set for a destination
subscriber, they can be transferred to other destination subscribers that require the same
parameters. Follow the steps outlined below:
1. Select a destination subscriber for which you have already set the parameters in the list
box.
2. Select "Copy" in the shortcut menu (right mouse button).
3. Select a second destination subscriber in the list box.
4. Transfer the parameters to this other destination subscriber using "Paste" in the shortcut
menu.
Objects: Overview table
Transmission direction of the objects
The transmission direction of the objects can be seen in the name suffixes _S or _R (send or
receive):
●
send direction
– Use in the station type "station" for the monitoring direction (in)
Station sends message to master station.
– Use in the station type "master station" for the control direction (out)
Master station sends message to station.
●
Receive direction
– Use in the station type "station" for the control direction (out)
Station receives message from master station.
– Use in the station type "master station" for the monitoring direction (in)
Master station receives message from station.
Overview of the TD7onTIM objects
Table 6- 5 System objects of TD7onTIM
WatchDog Monitoring of the CPU-TIM connection
Indicates to the CPU whether the communication between CPU and local
TIM is still working; in other words, whether TD7onTIM is still reading from
and writing to the memory areas of the CPU.
