Siemens TIM 4R-IE DNP3 User Manual

Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
284 System Manual, 12/2015, C79000-G8976-C253-04
Event ID
(hex)
Detailed
event
(hex)
Meaning
F560
011E
Bad TCP/IP packet.
F560 011F Error setting a socket.
F560
0120
Error in ACCEPT socket.
F560
0121
TCP/IP connection termination by partner.
F560
0122
TCP/IP reception error.
F560
0123
TCP/IP send error.
F560
0124
TCP/IP connection number invalid.
F560
0125
Error receiving a CR-PDU.
F560
0126
Illegal access over TCP/IP.
F560
0127
Invalid PDU length.
F560
0128
KEEPALIVE expired.
F560
0129
Entering state: Connection information: Ethernet port problem.
F460
Exiting state: Connection information: Ethernet port OK.
F560
012A
Error in socket CONNECT job.
F560
012B
Error receiving a CC-PDU.
F560
012C
Unknown error code.
F560
012D
Maximum number of S7 connections exceeded.
WAN messages
F560
0300
Internal / external WAN interface: Installation of the WAN driver was aborted.
F360
0301
Internal / external WAN interface: WAN driver is installed.
F360 0302 Internal / external WAN interface: Connection to a subscriber established (incoming call; sub-
scriber number identified).
F560
0303
Bad organizational message from routing task.
F360 0304 Entering state: Internal / external WAN interface: Send buffer changed over to image.
F260
Exiting state: Internal / external WAN interface: Send buffer changed back from image.
F360
0305
Entering state: Internal / external WAN interface: Send buffer overflow occurred.
F260
Exiting state: Internal / external WAN interface: Send buffer overflow eliminated.
F960
0306
Bad message: max. number of destination subscribers exceeded.
F960
0307
Bad message: Unknown source subscriber number.
F960
0308
Bad message: S7 PDU not with AE ID = 2.
F960
0309
Entering state: Internal / external WAN interface: CTS disturbance occurred on modem.
F860
Exiting state: Internal / external WAN interface: CTS disturbance eliminated on modem.
F560
030A
Entering state: Internal / external WAN interface: USART error occurred.
F460
Exiting state: Internal / external WAN interface: USART error eliminated.
F360
030B
Entering state: Subscriber failed.
F260
Exiting state: Subscriber OK.
F360
030C
Entering state: Internal / external WAN interface: WAN driver disabled.
F260
Exiting state: Internal / external WAN interface: WAN driver enabled.
F360
030D
Entering state: Internal / external WAN interface: Subscriber call disabled.
F260
Exiting state: Internal / external WAN interface: Subscriber call enabled.
F360
030E
Entering state: Internal / external WAN interface: Subscriber call in subcycle.
