Siemens TIM 4R-IE DNP3 User Manual

Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
287
Event ID
(hex)
Detailed
event
(hex)
Meaning
F960
034A
Internal / external WAN interface: SMS server of the TIM has received an unknown message.
F960 034C Internal / external WAN interface: Short message (SMS) acknowledgment received from an
unknown mobile subscriber.
F360
034E
Internal / external WAN interface: Incoming call detected. Incoming calls are disabled.
F360 034F Internal / external WAN interface: Incoming call detected. DTR signal was activated.
F360
0350
Internal / external WAN interface: SMS server of the TIM was installed and started.
F360
0351
Internal / external WAN interface: SMS status, global status request/deletion.
F360
0352
Internal / external WAN interface: SMS status, single status request/deletion.
F360
0353
Internal / external WAN interface: Spontaneous SMS status message.
F960 0354 Internal / external WAN interface: Short message (SMS) acknowledgment incorrect. Format
or ID no. unknown.
F560 0355 Internal / external WAN interface: No send buffer could be made available for sending a short
message (SMS).
F960
0356
Internal / external WAN interface: The GSM module expects the PUC number.
F960
0357
Internal / external WAN interface: Telephone number of the SMS recipient could not be found.
F360
0358
Internal / external WAN interface: The GSM signal strength is xx dBm.
F360
0359
Subscribers cannot be blocked.
F360
035A
Internal / external WAN interface: GSM module detects wrong service ID.
F360
035B
Internal / external WAN interface: GSM module ready to receive.
F360 035C Internal / external WAN interface: The switchover to the image method for blocked messages
was forced.
F360
035D
Internal / external WAN interface: Threat of forced switchover to image method.
F360 035E Internal / external WAN interface: Threat of forced switchover to image method.
F360
035F
Internal / external WAN interface: Permanent connection already active.
F360 0360 Internal / external WAN interface: Maximum number of messages exceeded.
F360 0361 Entering state: Internal / external WAN interface: The data brake for the connection to a sub-
scriber was enabled.
F260 Exiting state: Internal / external WAN interface: The data brake for the connection to a sub-
scriber was disabled.
F960 0362 Internal / external WAN interface: After transferring the PIN to the GSM module, no network
contact could be established.
Messages with the detailed events 0400 ff. can be found in the section DNP3-specific diagnostics messages of the TIM
(Page 293).
Messages from the routing task
F560
0500
Installation of the routing program aborted.
F560
0501
Internal / external WAN interface: Receive task of the WAN driver unknown.
F560
0502
Receive task of the clock driver unknown.
F560
0503
Read time function unknown.
F560
0504
Receive task of the LAN task unknown.
F560
0505
Partner table unknown.
F560
0506
Error occurred receiving a message.
F560 0507 Unknown PDU received.
