Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
286 System Manual, 06/2014, C79000-G8976-C253-03
Event ID
(hex)
Detailed
event
(hex)
Meaning
F960
0306
Bad message: max. number of destination subscribers exceeded.
F960
0307
Bad message: Unknown source subscriber number.
F960
0308
Bad message: S7 PDU not with AE ID = 2.
F960
0309
Entering state: Internal / external WAN interface: CTS disturbance occurred on modem.
F860
Exiting state: Internal / external WAN interface: CTS disturbance eliminated on modem.
F560
030A
Entering state: Internal / external WAN interface: USART error occurred.
F460
Exiting state: Internal / external WAN interface: USART error eliminated.
F360
030B
Entering state: Subscriber failed.
F260
Exiting state: Subscriber OK.
F360
030C
Entering state: Internal / external WAN interface: WAN driver disabled.
F260
Exiting state: Internal / external WAN interface: WAN driver enabled.
F360
030D
Entering state: Internal / external WAN interface: Subscriber call disabled.
F260
Exiting state: Internal / external WAN interface: Subscriber call enabled.
F360
030E
Entering state: Internal / external WAN interface: Subscriber call in subcycle.
F260
Exiting state: Internal / external WAN interface: Subscriber call in main cycle.
F360
030F
Entering state: Internal / external WAN interface: Permanent call to a subscriber enabled.
F260 Exiting state: Internal / external WAN interface: Permanent call to a subscriber ended.
F360
0310
Entering state: Internal / external WAN interface: Lack of resources on a subscriber.
F260 Exiting state: Internal / external WAN interface: Lack of resources on a subscriber eliminated.
F360
0311
Entering state: Internal / external WAN interface: Alternative path changeover on.
F260
Exiting state: Internal / external WAN interface: Alternative path changeover off.
F560
0312
Internal / external WAN interface: No message memory available for new image element.
F560
0313
Internal / external WAN interface: Image element too large for image memory.
F560
0314
Internal / external WAN interface: Set number of subscribers exceeded in image.
F560
0316
Internal / external WAN interface: 'List of Active Stations' (LAS) not available.
F560
0317
Internal / external WAN interface: Error receiving a message.
F560
0318
Internal / external WAN interface: Error enabling message memory.
F560 0319 Entering state: Internal / external WAN interface: Communication with AMPLUS-L task
disrupted.
F460
Exiting state: Internal / external WAN interface: Communication with AMPLUS-L task OK.
F560
031A
Entering state: Internal / external WAN interface: Communication with clock driver disrupted.
F460
Exiting state: Internal / external WAN interface: Communication with clock driver OK.
F560
031B
Entering state: Internal / external WAN interface: Communication with routing task disrupted.
F460
Exiting state: Internal / external WAN interface: Communication with routing task OK.
F560
031C
Internal / external WAN interface: Modem command invalid.
F560 031D Internal / external WAN interface: Invalid dialing string or bad call number transferred to
modem when calling a subscriber.
F960 031E Internal / external WAN interface: Incorrect handshake PDU received from a subscriber.
F360
031F
Internal / external WAN interface: Own telephone connection occupied.
F960 0320 Internal / external WAN interface: Modem not replying.
F960
0321
Internal / external WAN interface: Access to called subscriber not permitted.
