Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
289
Event ID
(hex)
Detailed
event
(hex)
Meaning
F260 Exiting state: Internal / external WAN interface: The data brake for the connection to a
subscriber was disabled.
F960 0362 Internal / external WAN interface: After transferring the PIN to the GSM module, no network
contact could be established.
Messages with the detailed events 0400 ff. can be found in the section DNP3-specific diagnostics messages of the TIM
(Page 295).
Messages from the routing task
F560
0500
Installation of the routing program aborted.
F560
0501
Internal / external WAN interface: Receive task of the WAN driver unknown.
F560
0502
Receive task of the clock driver unknown.
F560
0503
Read time function unknown.
F560
0504
Receive task of the LAN task unknown.
F560
0505
Partner table unknown.
F560
0506
Error occurred receiving a message.
F560
0507
Unknown PDU received.
F560
0508
PDU with bad address received. Destination subscriber number not found.
F560
0509
No WAN driver available.
F560 050B Error enabling heap memory.
F560
050C
Installation of the routing program ended. All routing tables available.
F560
050D
Error occurred sending a message.
F560
050E
No resources for creating the destination address table.
F560
050F
Destination address table not created.
F560
0510
No resources for PDU copy.
F560
0511
No resources for copy of partner table.
F360
0512
Entering state: Internal / external WAN interface: Redundancy function activated.
F260
Exiting state: Internal / external WAN interface: Redundancy function deactivated.
F960
0513
Message with incorrect block length received or block length is zero.
F560
0514
Max. number of messages exceeded.
F560
0515
Error in time-of-day synchronization over LAN.
F560
0516
MesA - Error sending a message.
F560
0517
The partner table/substitute table of a subscriber does not exist.
F560
0518
Error releasing memory.
F560
0519
Error in the MesA memory management
F560
051A
Entering state: MesA - Start of indication of a message memory overflow.
F460
Exiting state: MesA - End of indication of a message memory overflow.
F560
051B
Entering state: MesA - Start of indication of a message memory overflow.
F460 Exiting state: MesA - End of indication of a message memory overflow.
F560
051C
Message memory overflow occurred.
F560
051D
Entering state: Start of indication of a message buffer overflow.
F460
Exiting state: End of indication of a message buffer overflow.
F560
051E
Entering state: Overflow of message buffer active.
