Configuration in STEP 7
5.1 Overview
TIM DNP3
82 System Manual, 06/2014, C79000-G8976-C253-03
Assigning parameters to the TIM
If you double-click on the TIM module, you open the parameter assignment dialog for the
TIM. You can then specify the required properties in a series of tabs.
Figure 5-3 S7-300 station with installed TIM and TIM parameter assignment dialog
