13
3.4 Electrical system
The electrical system is composed of:
- an electrical panel for system management;
- an operator interface on board machine;
- a series of junction boxes, electrical seats on board machine, wiring and cables.
It is manufactured according to IEC 60204-1 norm.
The electric cabinets are able to provide the protection of materials against external agents
(IP54 protection level). To access it insert the supplied key (to be assigned exclusively to
authorized personnel) in the latches placed on the frontal doors of each panel.
The list of electrical components and their wiring diagrams are attached to this manual
(SPARE PARTS LIST section).
Plate of identification and technical data
On the machine it is present a plate from which it
is possible to recover easily the data to be
communicated to the manufacturer in case of
problems or requests for spare parts etc. (ref. 1-
2-3-4). This plate also carries electrical technical
data for installation of the machine (ref. a-b-c-d).
1 - Model
2 - Serial number
3 - Machine code
4 - Year of manufacture
a - Nominal voltage
b - Nominal frequency
c - Nominal power
d - Nominal current
