Smipack FP6000CS - Insertion of Film Inside Drag and Waste Collection Devices

57
handle. The presence of the millimetric line (Q3) facilitates this adjustment operation.
8.7 Insertion of film inside drag and waste collection devices
Make sure to have activated “Manual” operating mode. Open the guide rolls (N) manually and
then turn the selector switch (O) to also open the two drive wheels (H) and to pass the front
part of the two film edges as shown in figure 8.7.2.
After having checked that the two film edges are perfectly aligned one to another, close the
guide rolls and drive wheels (H).
Fig. 8.6.1
Fig. 8.7.1
