Smipack FP6000CS - Doors Magnetic Sensors (3); Emergency Button (4)

7 - Use of the machine
40
7.6.2 Doors magnetic sensors (3)
Are opening doors anchored to the structure of the machine equipped with magnetic sensors
that disable the movement of all devices considered hazardous:
• sealing bar operation
• operation of conveyor belts
> In "Manual" mode with the doors open are active the functions:
• height adjustment of the squares
• unwinding of the film reel activated via the manual movement of the tensioning bar of the
film unwinder.
ATTENTION! It is strictly prohibited to circumvent the magnetic sensors placed on doors as
they can create very dangerous situations for the operator.
7.6.3 Emergency button (4)
There are easily accessible
emergency button on the machine.
This button with mechanical latching
and manual resetting is a device to
cut out power which should be
pressed to instantly stop the
machine in case of imminent
danger.
Fig. 7.6.2
Fig. 7.6.3
