6 - Machine installation
28
6.5 Positioning and leveling
Make sure that the floor where the machine will be installed is not uneven, impairing its normal
and correct positioning.
Remove the supports (1) which fix the machine to the pallet and then level the machine
carefully placing a level on the frame at the points shown in the figure.
First, act on the four side support feet blocking
them adequately with the nuts (2) and then
perform the same operation also for the two central
support feet.
It 'also important to check that between the
opening door of the machine and the frame are
presents the conditions of parallelism shown in the
following figure.
