29
Height adjustment of the machine's work surface varies depending on the model:
- from 785 mm to 945 mm for FP6000 - FP6000CS
- from 815 mm to 975 mm for FP8000CS
The machine can also be equipped with wheels which must be used only to facilitate eventual
movements.
6.6 Assembly carried out by user
This paragraph describes the assembly operations which, for transportation requirements,
must be performed by the user.
6.6.1 Assembly of film waste containment plate
Mount the containment plate (3)
shown in figure on the film waste
collection device and fix it by means of
the knob (4).
6.6.2 Assembly of protections on the outgoing side of the machine
Fix the sheet metal protections (5) and (6) fixing them to the plexiglass protection (7) using the
screws (8) and nuts (9) supplied.
