Smipack FP6000CS - Film and Reel Dimension Requirements

5 - Data and technical features
22
5.2 Features of the film and reel dimensions
Centre-folded film in polyolefin or polyethylene with the features indicated in the table can be
used for wrapping.
5.3 Film reel width calculation
For each change format, depending on the dimensions Y and H of the product to be packaged
it is necessary to calculate the range of reel.
with H≤100 mm :
FILM WIDTH = Y + H + 100 mm of waste
whit H>100 mm :
FILM WIDTH = Y + H + 150 mm of waste
where:
Y= width of product
H= height of product
5.4 Noise level of the machine
DECLARED NOISE EMISSION VALUES IN COMPLIANCE WITH THE STANDARD ISO 4871:
A-WEIGHTED EMISSION SOUND PRESSURE LEVEL (AT OPERATOR POSITION): 70 dB.
The noise levels specified have been determined while packaging plastic containers. For
products made of other materials (for example glass or tin) that require packaging, the noise
level may be greater than the value specified above.
9 to 30 my polyolefin
15 to 60 my polyethylene
(with use of the optional sealing bar for
polyethylene)
Ø maximum reel : 350 mm
Width (L) maximum reel:
- 600 mm (FP6000 - FP6000CS)
- 850 mm (FP8000CS)
