8 - Preparing the machine for use
60
8.9 Adjustment of position of squares
The squares normally protrude from the edge of the infeed belt by 5 mm as shown in figure 1.
However if you want to wrap the product in the smallest bag possible, the position can be
optimised. In order to do this, act on the screws (16) and (17) and move the squares in the
direction indicated in fig. 2.
Fig. 8.8.2
Fig. 8.9.1
