SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
Exit
NAME:
ID:
DATE OF BIRTH:
Johnson
NH_23482
12/11/1982
10052010.ppm
Figure 4.3: File manager: patient directory
Figure 4.3 illustrates the patient directory.
The function of the icons shown in the file manager are listed in Table 4.1.
Icon Action upon clicking the icon
Go to parent directory.
Search file by name.
Copy the selected files to the cache.
Paste the cached files to the current file folder.
Delete the selected files.
Convert the selected files to the PC format.
Display report files only.
Display image files only.
Enable multi-selection.
Display report files only.
Export selected files to remote Service Class User (SCU).
Load/Unload the USB drive. Note that the USB drive can
be automatically unloaded upon clicking the Exit button.
Table 4.1: File operations
P/N: 4701-0061-01B
4-3
