Spectra Precision Focus 6 5" Total Station User Guide 123
Menu Key 5
The coordinates are stored as a CC record. Line
definition information and Sta, O/S, and dVD values are
stored in comment (CO) records.
Calculating coordinates using intersection functions
To enter the Intersection menu, press [3] or select Intersection in the Cogo menu.
There are four functions in this menu for calculating coordinates.
Calculating a bearing-bearing intersection
A bearing-bearing intersection is the intersection point of two lines.
1. To calculate a bearing-bearing intersection, press
[1] or select Brng-Brng in the Intersection menu.
2. Enter the first point name and press
[ENT].
Alternatively, to measure directly to the point,
press the
MSR softkey.
3. Define the first line by azimuth.
4. To define the line by two points, press the
Pts
softkey. The Fr field defaults to the P1 point, but
you can change the selected point. In the To field,
enter or measure to the second point.
For more information about the
O/S softkey, see
Advanced feature: Entering angle and distance
offsets, page 127.
5. Do one of the following:
– To return to the previous screen, press [ESC].
The calculated value appears in the AZ field.
– To go to the next screen, press [ENT].
