Spectra Precision Focus 6 5" Total Station User Guide 71
Applications 4
HRx is not updated even if the instrument is moved.
6. Press
[ENT] to store the foresight as a CP record.
Check the PT, HT, and CD values. Then press
[ENT]
to record.
In repeat angle measurement, the HA is replaced
by HR
. The number of repeat angles appears at
the top of the screen ( for example,
N= 5).
Horizontal angles can be measured up to 1999°59'59". This function stores both
raw and XYZ data as CP records, regardless of the Store DB setting.
Horizontal angle hold
To hold the horizontal angle to the current value, press
[5] or select Hold in the Angle menu.
To set the horizontal angle to the displayed value, press
[ENT] or the Set softkey.
To cancel the process and return to the Basic
Measurement Screen (BMS), press
[ESC] or the Abrt softkey.
Station setup
To open the Stn Setup menu, press [STN] in the BMS.
To select a command from this menu, press the
corresponding number key. Alternatively, press
[<] or [>]
to highlight the command and then press
[ENT]. Press [^]
or
[v] to move up or down one page.
The last function used is highlighted.
Setting up a station with known coordinates or
azimuth
1. Press [1] or select Known in the Stn Setup menu.
2. Enter a point name or number in the ST field.
– If the input point number or name is an
existing point, its coordinates are displayed
and the cursor moves to the HI (Height of
instrument) field.
