5 Menu Key
132 Spectra Precision Focus 6 5" Total Station User Guide
B
Tip – If you select US-Ft or I-Ft, an additional settings
screen appears. Use this screen to specify whether to
display values in Decimal-Ft or
Ft-Inch.
B
Tip – The Angle, Distance, Temp, and Press job settings cannot be changed once a job is
created.
Recording
To open the Rec menu, press [8] or select Angle in the
Settings menu.
Others settings
To open the Others menu, press [9] or select Others in
the Settings menu.
Temp °C (Celsius)
°F (Fahrenheit)
Press hPa/mmHg/inHg
Store DB RAW/XYZ/RAW+XYZ
This setting determines whether raw and/or
coordinate data is stored when you record SS,
CP, or SO records in the Basic Measurement
Screen (BMS) or Stakeout screen.
Data Rec Internal/COM
Set this field to COM to output data on the
COM port when you press [ENT] in the BMS or
a Stakeout screen. The data is not stored to
the job file. For more information, see
Outputting data to the COM port, page 100
XYZ disp Fast/Norm/Slow/+ENT
Defines speed to move to the next screen
after showing XYZ of the input PT
2nd Unit None/Meter/US-Ft/I-Ft
When the Secondary unit is set to a unit, an
extra display screen is available in the BMS,
stakeout observation screens, and 2-pt
reference line screens. The extra screen shows
the HD, VD, and SD in the secondary unit.
