Spectra Precision Focus 6 5" Total Station User Guide 181
Communications 9
SDR2x and SDR33 record formats
Header record
Instrument record
00NM ver 0000 datetime ang dist press temp coor 1
1–4 00NM Header record identifier (fixed text)
5–20 ver SDR download version. One of the following:
SDR20V03-05 SDR2x
SDR33V04-01 SDR33
21–24 0000 Not used
25–40 datetime Download date and time (in hours and minutes)
41 ang Angle units. One of the following:
1 Degrees
2 Gons
4 Mils
42 dist Distance units. One of the following:
1 Meters
2 Feet
43 press Pressure units. One of the following:
1 mm Hg
2 In. Hg
3 hPa
44 temp Temperature units. One of the following:
1 Celsius
2 Fahrenheit
45 coor Coordinate order. One of the following:
1 NEZ
2 ENZ
46 1 Not used
01KI1 instr serNo Instr serNo 1 zero VA 0.000 0.000 0.000
1–5 01KI1 Instrument record identifier (fixed text)
6–21,
28–43
instr Instrument make and model
22–27,
44–49
serNo Instrument serial number
50 1 Not used
51 zero VA The reference point for vertical angles. One of the
following:
1 Zenith
