4 Applications
96 Spectra Precision Focus 6 5" Total Station User Guide
4. Loosen the vertical clamp, and turn the telescope
to aim at an arbitrary point.
The difference in elevation (Vh) appears.
B
Tip – You can use an REM measurement to update the
height of target. Take a measurement to the prism, sight
the bottom of the prism pole, and press [ENT].
Measuring distance and offset values on the vertical plane
1. To enter the 2-Pt Reference Plane function, press [6]
or select
V-Plane in the Programs menu.
2. Enter two points to define the plane.
To enter the point by direct measurement, press
the
MsrPT softkey.
When you press the
MSR softkey, a temporary
observation screen appears.
3. Press
[MSR1] or [MSR2]. The Record PT screen
appears.
4. Enter a value in the PT and CD fields. Press
[ENT].
Baseline
