5 Menu Key
128 Spectra Precision Focus 6 5" Total Station User Guide
Settings
To display the Settings menu, press [2] or select
Settings on the MENU screen.
Use this menu to configure the initial job settings.
B
Tip – Some job settings, specified in the following
sections, cannot be changed once a job is created. If any
of these settings are changed while a job is open, a
confirmation screen appears, asking you to create a new
job with the new settings, or to work with those settings
without recording any data. For more information, see
Settings, page 194.
Angle
To open the Angle menu, press [1] or select Angle in
the Settings menu.
B
Tip – The VA zero job setting cannot be changed once a
job is created.
B
Tip – The HA job setting cannot be changed once a job is created.When this field is set to
Azimuth, the horizontal angle (HA) that appears and recorded is in Azimuth value. When
this field is set to 0 to BS, HA is in HA zero to BS value.
Distance
To open the Distance menu, press [2] or select Distance in the Settings menu
B
Tip – The Scale, T-P corr., Sea Level, and C&R corr. job settings cannot be changed once a
job is created.
VA zero Zenith/Horizon/Compass
Resolution 1"/5"/10" or 0.2 mgon/1 mgon/2 mgon
HA 0 to BS/Azimuth
Scale Numeric value between 0.999600 and
1.000400
T-P corr. ON/OFF
Sea Level ON/OFF
C&R corr. OFF/0.132/0.200
To Next Page
