Spectra Precision Focus 6 5" Total Station User Guide 35
Setting up the Instrument 2
Make sure there are no obstacles between the instrument and the target when taking
measurements. When you need to take measurements across a road or a place where
vehicles or other objects are frequently moving, take several measurements to a target
for the best result.
Preparing the reflector sheet
The reflector sheet can be used for measurements in Prism mode. Assemble the
reflector sheet as shown below.
Reflector
sheet
Mini prism
adapter
Telescopic
prism pole
Prism pole
tripod type PPS
