5 Menu Key
144 Spectra Precision Focus 6 5" Total Station User Guide
Entering coordinates
In the XYZ screen, press the Input softkey to display a
new input point screen.
The PT field defaults to the last recorded PT + 1, but
you can change the value shown.
Enter the PT and CD and then press
[ENT] to enter
coordinates.
Use the numeric keys to enter the coordinates. Press
[ENT] or [v] in each field to move to the next field.
When you press
[ENT] in the CD field, the point is stored
as an MP record.
After you have recording a point, the next point input
screen is shown with the updated default PT.
B
Tip – You can record NE, NEZ, or Z-only data to the
database.
Point name list and code list
The instrument stores two list files: a list of PT names and a list of CD names. The
structure and functionality of these files is the same.
• The PT name list is useful if you have to handle more than one patterns of point
names in the field. For example, you may need to use points named 1, 2, 3 …, as
well as points named A1, A2, A3 ….
• The code list is a prepared list of feature codes. You can use it to store your own
codes.
Press
[4] or select PT name List in the Data menu to
open the point name list.
Press
[5] or select Code list to open the code list.
The point or code names and layers are shown in
alphabetic order. Use the four softkeys to customize the
list.
