9 Communications
176 Spectra Precision Focus 6 5" Total Station User Guide
Uploading Point Lists and Code Lists
Settings
To configure the transmission speed and other settings,
go to
MENU > Settings > Comm. For more
information, see Communications, page 131.
File format
PT lists and code lists use the same record format. Use the filenames POINT.LST for a
PT list, and CODE.LST for a code list.
Figure 9.1 Record format for PT lists and code lists
DEFAULT
{
String1 , Code1
Layer2
{
String2-1, Code2-1
String2-2, Code2-2
}
Layer3
{
Layer 3-1
{
String3-1-1, Code3-1-1
String3-1-2, Code3-1-2
}
String3-2, Code3-2
String3-3, Code3-3
}
String4, Code4
String5, Code5
String6, Code6
String7, Code7
}
The first line of the file must
contain the text “DEFAULT”
in capital letters.
Curly brackets { } group
items together under the
preceding line.
For example, Layer 3-1
contains String 3-1-1 and
String 3-1-2.
Layer 3 contains the five
items from Layer 3-1 to
String 3-3.
“String” represents
characters that are
displayed on the screen.
“Code” represents
characters that are stored in
