2 Setting up the Instrument
28 Spectra Precision Focus 6 5" Total Station User Guide
Detaching the battery pack
C
CAUTION – Avoid touching the contacts on the battery pack.
1. If the instrument is turned on, press [PWR] to turn it off.
2. Turn the battery box release knob counterclockwise, open the battery box cover
and then pull the battery pack out of the battery box.
Attaching the battery pack
1. Clear any dust or other foreign particles from the battery contacts.
2. Turn the battery box release knob
counterclockwise and then open the battery
box cover.
3. Put the battery pack into the battery box.
Connect the battery pack at the bottom with
the connecting direction faced inside.
4. Close the battery box cover and then turn the
knob clockwise until you hear a click sound.
C
CAUTION – If the battery pack cover is not closed, this could adversely affect the
watertightness of the instrument.
