Spectra Precision Focus 6 5" Total Station User Guide 55
Getting Started 3
B
Tip – To change the type of data that is assigned to the
[USR] keys in MENU > 1sec-Keys > [USR]. For
more information, see [USR] key settings, page 153.
[DAT] button
Use the [DAT] key to quickly access data in the current job from observation screens.
When you press
[DAT] in the BMS or in observation
screens in functions such as Stakeout, 2Pt RefLine, and
Arc RefLine, the assigned data in the current job
appears.
Hold down
[DAT] for one second in the BMS or an
observation screen to display the Select Format screen.
Use this screen to change the type of data that is
assigned to
[DAT]. Press [1] or select DAT [MENU] to
display the Data menu whenever you press
[DAT].
When you select an option from this screen, the change
is applied immediately, and the selected data type
appears.
Press
[ESC] to return to the previous observation screen.
B
Tip – To change the type of data that is assigned to [DAT],
go to MENU > 1sec-Keys > [DAT]. For more
information, see [DAT] key settings, page 153.
Turning on the instrument
Press the [PWR] button. The start-up screen appears. It
shows the model name, current temperature, pressure,
date, and time. The display automatically changes to
the electronic level after two seconds.
If you entered your name or your company’s name in
the Owner’s detail field, the text from this field appears
on the start-up screen. To set the Owner’s detail field,
press
[MENU] and then select Settings / Other.
See also Others settings, page 132.
