Parts of the instrument
Figure 3.1 and Figure 3.2 show the main parts of the Focus6 5" total station.
Figure 3.1 Back view of the Focus6 5" total station (Face 1)
Telescope
Telescope
Diopter ring
Carrying
Vertical tangent
Horizontal
screw
tangent screw
focusing ring
handle
eyepiece
Face 1 display and
keyboard
The laser safety label shown
below is attached to the
Optical sight
(finder)
Horizontal axis
indication mark
Battery box
Battery box
release knob
Reticle plate cover
Complies with 21 CFR 1040 . 10 and 1040 . 11
except for deviations pursuant to
Laser Notice No . 50 , dated June 24 , 2007
MADE IN JAPAN
Technoport Mitsuiseimei Bldg.
16
-
2,Minamikamata 2
-
chome,
Ota
-
ku, Tokyo 144
-
0035 Japan
NIKON
-
TRIMBLE CO.,LTD.
underside of the keyboard.
Tribrach clamp
knob
The label shown below is
attached to the underside
of the keyboard.
