Z001019/0_8_Octobre 2011 Page GENERAL-29
GENERAL
SERVICE MANUAL MARINE ENGINES
ToC
12. Remove the air filter, plug the exhaust elbow and
remove the inlet pipe to the tandem/triple cooler,
see photo. See ill.3 and ill.4
13. Fill a spray bottle with the preservation oil
(art.nr. Z050323-0, 5 liter canister, adequate quantity
incl. in all Preservation Service Kits).
14. Whilst cranking the engine over, by turning the start
key, spray the preservation oil into the turbo inlet.
See ill.5
15. Continue this process for 20 to 30 seconds.
16. Refit the fuel feed line to the engine, ensure fuel supply
and turn the ignition on, the fuel pump runs for 10 sec
automatically refilling the fuel system. Repeat until
fuel comes from the return line.
NOTE: For corrosion protection of fuel system leave
system filled with preservation fuel Z010014-0 till
next preservation or engine is put into operation.
17. *Only by 2
nd
Preservation:
After two years engine storage replace engine coolant
water (art. nr. Z011785-0, 5 liter canister, adequate
quantity incl. in 2
nd
Preservation Service Kit) and fill
between min/max-level in coolant expansion tank.
18. Replace all pipes and connections to original condition
and restore engine.
19. Record carried out Storage Preservation Procedure
in following documents:
1) STEYR MOTORS WARRANTY REGISTRATION
CARD
(to find under: Operation, Maintenance and Warranty
Manual Z001022/ chapter WARRANTY)
2) COMMISSIONING REPORT
(to find under: Installation Manual Z001007/0 /
chapter 19. APPENDIX)
Ensure notification in above documents for approval
of extended STEYR MOTORS BASE ENGINE
WARRANTY.
Otherwise BASE ENGINE WARRANTY will end for
PLEASURE /COMMERCIAL duty after 1 year
starting from STEYR MOTORS manufacturing date.
NOTE: For manufacturing date, see on engine carton!
See ill.6
20. Note the date of preservation on:
1) sticker for engine-carton (sticker incl. in corres-
ponding Preservation Service Kit) - see ill.6
ill. 5
ill. 6
