Stihl MS 362 Manual

116 MS 362, MS 362 C
: Push the generator wire and
connector (1) into the guides
(arrows) as far as stop.
Make sure the wire is below the
edge (2).
: Position the wire (1) below the
connector (arrow).
1
0001RA452 TG
2
0001RA470 TG
1
The wire (1) must be properly
seated in the guide (arrow) and not
project.
The flywheel must not touch the
generator wire
– this could cause a break in power
supply.
– Reassemble all other parts in the
reverse sequence.
0001RA453 TG
1

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
