123MS 362, MS 362 C
14. Special Servicing Tools
Existing Special Tools
No. Description Part No. Application Rem.
1 Carburetor and engine tester 0000 850 1300 Testing engine and carburetor for leaks
- Nipple 0000 855 9200 Testing carburetor for leaks
- Hose for leakage test 1110 141 8600 Testing carburetor for leaks
- Plug for leakage test 1122 025 2200 Leakage testing decompression valve
2 Installing tool 0000 890 2201 Installing rope guide bushing
3 Clamping strap 0000 893 2600 Compressing the piston rings
4 Locking strip 0000 893 5903 Blocking the crankshaft
5 Pliers DIN 5254-A 19 0811 611 8380 Removing and installing external
circlips
6 Screwdriver bit, T 27 x 125 0812 542 2104 Removing and installing spline socket
screws with electric or pneumatic
screwdrivers; tightening down screws
with torque wrench
7 Wooden assembly block 1108 893 4800 Supporting the piston
8 Setting gauge 1111 890 6400 Adjusting air gap between the ignition
module and flywheel
9 Assembly drift 1114 893 4700 Removing and installing piston pin
10 Assembly tube 1117 890 0900 Attaching springs
11 Installing sleeve 1118 893 2401 Installing oil seal
(clutch side)
12 Installing sleeve 1122 893 2405 Installing oil seal
(starter side)
13 Installing sleeve 1122 893 4600 Protecting the oil seal
(clutch side)
14 Combination wrench 1129 890 3401 Spark plug 1)
15 Puller 1135 890 4500 Removing flywheel
16 Service tool AS (set) 5910 007 2205 Removing and installing crankshaft
(clutch side)
- Screw sleeve 5910 893 2409 Pulling two halves of crankcase
together
New Special Tools
No. Description Part No. Application Rem.
1 Test flange 1140 890 1200 Leakage Test
2 Service tool ZS (set)
including
Drilled plate 5910 893 2103
5910 007 2201 Removing and installing the crankshaft
(starter side)
- Drilled plate
for service tool ZS (set)
5910 007 2200
5910 893 2103 Pulling two halves of crankcase
together
