50 MS 362, MS 362 C
: Disconnect the short circuit
wire (1).
: Take out the screws (2).
: Remove the ground wire (3).
– Remove the ignition module.
: Pull the grommet (1) off the
ignition module.
: Unscrew the ignition module (3)
from the ignition lead (2).
– Check the spark plug boot and
ignition lead, and replace if
necessary, b 7.5
1
3
0001RA153 TG
2
2
0001RA156 TG
1
2
3
– Troubleshooting, b 3.5
– Before installing the ignition lead,
fill the high voltage output with
STIHL multipurpose grease
b 15.
Do not use either graphite grease or
silicone insulating paste.
– Reassemble in the reverse
sequence.
Make sure the grommet (1) is fitted
properly to avoid ignition system
problems that may be caused by
contamination or moisture.
Installing
Machines with Heating
Before installing the ignition
module, check that the generator
wire (arrows) is properly positioned,
b 13.7.
0001RA157 TG
: Fit the ignition module (1) and
insert the screw (arrow)
– do not tighten down yet.
: Fit the ground wire (3) and insert
the screw (2) – do not tighten
down yet.
Crimped side of terminal must face
the screw head.
: Push the ignition module back
and slide the setting gauge (1)
1111 890 6400 between the arms
of the ignition module and the
flywheel magnet.
1
0001RA158 TG
3
2
0001RA159 TG
1

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
