73MS 362, MS 362 C
: Take out the screw (1) and
remove the bracket (2).
: Take out the screws (1).
: Ease the handlebar (1) sideways
and take it out of the guide
(arrow).
0001RA237 TG
1
2
0001RA238 TG
1
1
0001RA239 TG
1
: Push the handlebar (1) out of the
lower guide.
During all the following procedures:
: To reduce the risk of a short
circuit, make sure the insulating
tubes completely cover the
connections.
– Pull the wires out of the guides.
: Tug the wiring harness (1) a little
to find the right connector.
0001RA240 TG
1
165RA267 TG
0001RA476 TG
1
: Push the insulating tube (1) in the
direction of the heating element.
: Separate the pin and socket
connector.
: Pull the generator wire out of the
guides (arrows).
It is not necessary to disconnect the
connector.
: Pull the connector sleeve with
wire (1) out of the heater switch.
0001RA241 TG
1
0001RA157 TG
0001RA341 TG
1

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
