11-16 Sun Ultra 45 and Ultra 25 Workstations Service and Diagnostics Manual • May 2006
The following warning message example indicates that there is a DIMM size
mismatch in slots DIMM0 and DIMM1:
DIMM0 is a 1-GByte DIMM and DIMM1 is a 512-MByte DIMM.
11.4.3 Info Messages
Info messages are simple and are only preceded by the text, INFO. Info messages
provide noncritical facts, as seen in this example:
These info messages indicate that a 1-GByte DIMM is installed into each DIMM
connector.
11.5 Setting Up for POST
To execute POST and view its output, you must perform the procedures in the
following sections.
11.5.1 Verifying the Baud Rate
Ensure that the communication parameters are correct. Use one of the following
procedures:
0>WARNING: TEST = Probe and Setup Memory
0>H/W under test = CPU0 Memory
0>MSG = DIMM size does not match for Dimm set 0, Dimm0=
00000000.40000000, Dimm1=00000000.20000000
0>END_WARNING
0>Probe and Setup Memory
0>INFO: 1024MB Bank 0, Dimm Type X4
0>INFO: 1024MB Bank 1, Dimm Type X4
0>INFO: 1024MB Bank 2, Dimm Type X4
0>INFO: 1024MB Bank 3, Dimm Type X4
