Sun Microsystems Ultra 25 - Motherboard Connector Overview; FIGURE 3-1 Motherboard with Component Connections

3-2 Sun Ultra 45 and Ultra 25 Workstations Service and Diagnostics Manual • May 2006
3.1 Motherboard Connector Overview
FIGURE 3-1 and FIGURE 3-2 show the connections for some cables and devices that
connect to the motherboard.
FIGURE 3-1 Motherboard With Component Connections
P4
not used
