8-6 KICK STARTER
• Install the kick starter assembly to the crankcase. Hook the
return spring 2.
• Reassemble the kick idle gear 5.
• Reassemble the primary driven gear assembly and clutch.
(7-5, -7)
• Install the crankcase cover.
 Crankcase cover bolt: 11 N·m (1.1 kgf-m, 8.0 lb-ft)
• Install the kick starter lever so the punch mark on the lever
aligns with the punch mark on the kick shaft.
 Kick starter lever bolt: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
INSPECTION AFTER REASSEMBLY
After reinstalling the kick starter assembly, inspect the follow-
ings.
• Transmission oil level (2-9)
• Engine coolant level (2-10)
• Brake pedal height (2-19)
• Clutch lever play (2-12)
