Suzuki RM125 - Rear Wheel; Removal; Inspection

14-6 FRONT AND REAR WHEELS
REAR WHEEL
REMOVAL
• Place the motorcycle on a block to lift the rear wheel off the
ground.
• Remove rear axle nut 1 and washer 2.
• Remove the rear axle shaft 3 and chain adjuster washers 4.
• Disengage the drive chain.
• Remove the rear wheel.
INSPECTION
WHEEL SPACER
• Inspect the rear wheel spacers 1 and dust seals 2 for wear
and cracks.
• If any damage is found, replace the spacer together with the
dust seal.
NOTE:
Apply grease on the spacer and dust seal before reassembling.
AXLE SHAFT (14-3)
WHEEL RIM (14-4)
WHEEL BEARING (14-4)
