Suzuki RM125 - Inspection; Reassembly

CLUTCH 7-7
INSPECTION
• Inspect the clutch sleeve hub and primary driven gear assem-
bly for wear and cracks.
• Inspect the kick starer idle gear, needle bearing and spacer
for damage and wear.
REASSEMBLY
• Apply transmission oil to the spacer 1 and needle bearing 2.
• Install the kick starter idle gear 3, washer 4 and snap ring
5.
 09900-06107: Snap ring pliers
• Install the primary driven gear assembly 6.
• Install the washer.
• Fit the clutch sleeve hub 7, new lock washer 8 and clutch
sleeve hub nut 9.
NOTE:
The flat side of the nut 9 must face inside.
