18-12 SERVICING INFORMATION
WIRE, CABLE AND HOSE ROUTING
Clutch cable
Clutch cable
Throttle cable
Clutch cable
Throttle cable
Throttle cable
Clamp
Pass through the clutch cable
under the radiator breather hose.
Pass through the clutch
cable between the engine
mounting plates.
