6-12 CYLINDER, PISTON AND EXHAUST VALVE
EXHAUST VALVE GOVERNOR REMOVAL
AND DISASSEMBLY
• Drain transmission oil. (2-9)
• Drain engine coolant. (12-3)
• Remove the exhaust pipe. (5-3, -4)
• Remove the exhaust valve rod bolt. (6-4)
• Remove the right crankcase cover. (8-3)
• Remove the exhaust valve governor 1.
• Remove the exhaust valve rod assembly 2.
• Remove the pin 3 by pushing down the retainer 4.
• Disassemble the following parts from governer.
1 Governer 8 Washer
3 Pin 9 Spacer
4 Retainer 0 Washer
5 Spring A Bearing
6 Retainer B Stater
7 Bearing C Balls
