17-8 REAR SUSPENSION
• Pour the fresh specified rear suspension oil as shown while
moving the rod.
NOTE:
Be sure to extend the rod after filling the oil.
• Tilt the shock absorber unit as shown and pour the fresh rear
suspension oil fully into the reservoir tank.
99000-99001-S25: SUZUKI REAR SUSPENSION OIL
SS-25
(or equivalent rear suspension oil)
Oil capacity: Approx. 380 ml (12.84/13.38 US/Imp oz)
• Cover the compression adjuster hole with the root of your
thumb.
• Tilt and shake the rear shock absorber unit to fill the reservoir
tank with the oil.
• Add the oil and repeat the above procedure until the reservoir
tank is filled with the oil completely.
• Replace the O-rings on the compression adjuster assembly
with new ones.
