5-6 ENGINE REMOVAL AND INSTALLATION
• Unhook and extract the clutch cable D.
NOTE:
Loosen the clutch cable adjuster when disconnecting.
(2-12)
• Remove the engine mounting bolts and plates.
• Remove the swingarm pivot nut E and washer.
• Extract three quarters of the swingarm pivot shaft so as to
keep the swingarm in position.
NOTE:
The swingarm will come off when the swingarm pivot shaft is
completely removed.
• Dismount the engine from the frame.
To Next Page
