12 Software description
CyFlow
®
Cube 8 | Operating Manual | May 2018 | Revision 032 101
Scaling Mismatch: A mismatch between listmode and Workspace scale
can occur. In this case, the LMD file is replaced, and the Workspace is
modified to match the LMD file settings. Any zoom settings that have
been applied are reset. A corresponding message is displayed as soon
as the LMD file is opened in the Workspace. As long as mismatched
LMD files are not open in the Workspace, they are coloured orange in the
Playlist and contain a corresponding tooltip.
Compensation Values When Replacing Listmode: If the Playlist item
has no associated compensation file, compensation values will be
obtained from the new listmode file. If the Playlist item has an associated
compensation file, compensation values will be obtained from the
compensation file.
If a parameter mismatch occurs, opening the LMD file will remove the
compensation file applied from the Playlist. A corresponding message is
displayed. Select Yes to replace the listmode and remove the
compensation file applied. Select No if you do not wish to replace the
listmode file.
If the Playlist item has a modified compensation, a corresponding
message is displayed. Select Yes to keep all modified compensation files
in the Playlist and apply them to the replaced LMD file. Select No to clear
the modified compensation values. The compensation values in the
replacement LMD file will be used instead. Select Cancel to cancel the
replacement of the listmode file.
Workspace group
The Workspace group contains options to modify the Workspace file
associated with Playlist items.
The Workspace group contains the following buttons:
Replace: The button is enabled when one or more Playlist items are
selected in the Playlist. To replace the Workspace for the selected
Playlist items, click the button and select the desired replacement
Workspace.
When replacing Workspace files, a parameter mismatch may occur
between the listmode file of the Playlist item and the Workspace file. If
the Playlist item is open in the Workspace, the Parameter Resolver
dialogue is displayed allowing you to resolve the mismatch. If the Playlist
item is not open in the Workspace, an error state is displayed in the
Playlist for that Playlist item. The Playlist item text is displayed in red and
contains a corresponding tooltip. Open the Playlist item in the Workspace
to open the Parameter Resolver dialogue.
Save as: The button is enabled when a single Playlist item containing a
Workspace is selected in the Playlist. Click the button to save the current
Workspace file with a new file name.
