3Overview
CyFlow
®
Cube 8 | Operating Manual | May 2018 | Revision 032 15
Fig. 3.2 Ports for external devices
Fig. 3.3 Rear side of the device
1 USB port
2 HDMI port
3 VGA port
4 Ethernet port
5 USB port
6 Ethernet port
7 Audio port
8 Audio port
9 USB port
10 USB port
11 USB port
12 DVI port
13 USB port
14 Keyboard port
15 Mouse port
1 Fuse insert (T 4.0 A 250 V)
2 Power switch
3 Connector socket for the power cord
15
7
1 3
1213 91011
2 4 5 6
8
14
2
1
3
